Slitting Machine (FQ-1300B)
Main Technical Parameter
| Technical Parameter | Value |
| Model | FQ-1300B |
| Diameter Of Unwind | Φ600MM |
| Diameter Of Rewind | Φ450MM |
| Slitting Width | 50-1300MM |
| Min.Slitting Width | 20MM |
| Unwind Paper Core Inner Diameter | 3’ Inch |
| Max.Slitting Speed | 200M/MIN |
| EPC Precision | ≤ ±0.3MM |
| Machine Total Power | 4KW |
| Machine Weight | 2000KG |
| Machine Overall Dimension | 1570×2700×1500MM |
FQ-B Series
- Machine Speed 200M/MIN
Suitable Material
- Laminated Film,BOPP,PET,PVC & Metalize Film.etc
Main Specifications
- One-Motor Drive; Siemens PLC
- Unwind Material Roll Loading / Unloading Shaft Type
- Unwind with Chinese Famous Brand Web Guide
- Rewind With Standard Air Shafts
